Description
Package Includes: the extended tank drain assembly kit comes with braided steel hose, 1/4 inch NPT, 1/4 inch – 3/8 inch brass adapter and threaded sealing tape; The 110V electronic drain valve is a split set; The main material is brass, which is sturdy and reliable, and can meet your needs
Hose Kit: equipped with a 10 inches flexible braided steel hose to avoid cracking and kinking; This valve kit works with 1/4 or 3/8 inch NPT drain valve; Working Pressure: 175 PSI; Blasting Pressure: 475 PSI/ Max; Temperature: 200 degrees Fahrenheit
Electronic Timing Drain Valve: power supply voltage: AC 110V-120V/50Hz; Type: 2 way direct acting valve, widely applied in air storage tanks and drip legs
Timing: the automatic timed water tank is flexible and can be programmed; The matching conditions can be achieved by discharging condensate at regular intervals; The drainage time: 0.5 – 10 seconds, the interval time: 0.5 – 45 minutes; You can also adjust the drainage duration and drainage interval according to the actual situation
Multi Functional and Compatible Timing: the automatic timed water tank is flexible and can be programmed; Using a 1/ 2″ design American plug, The matching conditions can be achieved by discharging condensate at regular intervals; The drainage time: 0.5 – 10 seconds, the interval time: 0.5 – 45 minutes
